產品詳細
應用行業:
地板、墻板,、服裝打樣,、大幅面截?cái)?、皮革業,、鞋業、裝飾業,、家具業,、廣告業、包裝印刷業,、模型業,、工藝禮品業等。
適用材料:
木材,、木地板,、復合材、木皮,、布料,、皮革、亞克力,、紙張,、竹木制品、有機玻璃,、玻璃,、薄膜、帆布等,。
機型特點:
For application in following business lines: Flooring, wall panels, textile samples, leather, shoes, decorative products, furniture, advertisement, packaging screening, mold-making, handcrafted souvenirs
Suitable materials: Wood, wood board, engineered board veneer, fabric, leather, acrylic, paper, bamboo-made items, organic glass, glass, thin film, canvas, etc
Special features:
1.Equipped with the system specially applied for laser cutting, with high speed and high precision.
2. Imported linear guide rail, high-speed stepping motor and driver are selected to make the edge of cutting effect smooth and ripple-free.
3.Integrated frame structure design adopted to make the machine run stably without noise
4.It is easy to operate. Cutting and steps of processing can be done in order, partially operated or for one-time output, at the operator’s liberty. Offline system allows you to design the program on one computer with the work on multiple machines for energy-saving purpose.
5.Laser power, speed and focus distance can be adjusted.
6.Software interface is compatible with Auto Cad, Coredraw, Photoshop, etc
7.Equipped with water cut-off protector to better protect the laser and extend the service life of the laser machine
產品型號Model No.: |
EX-1390J |
激光功率Laser Power: |
150W |
激光器類型Laser Type: |
CO2 封離式玻璃管激光器,水冷,,10.6um |
|
Sealed Glass CO2 Laser tube, water cooling, 10.6micron |
有效幅面Working Area: |
1300mm×900mm |
傳動方式Carriage method: |
皮帶傳動 |
驅動電機Driving Motor: |
步進電機 |
冷確方式Cooling Method: |
水冷 |
雕刻掃描速度Scanning speed for engraving |
0-70000mm/min |
最大運動速度Max.moving speed |
70000mm/min |
切割速度Cutting speed |
0-40000mm/min |
激光能量控制Laser power controller |
1-100%軟件設定software set-up |
最小成形文字Small text: |
漢字 2.0mm×2.0mm 英文 1.0mm×1.0mm |
|
Chinese 2.0mm×2.0mm English: 1.0mm×1.0mm |
最大掃描精度Max scanning definition |
2500DPI |
定位精度Focus precision |
≤±0.01mm |
支持的圖形File format: |
DST,、PLT、BMP,、DXF,、AI |
分色切割Cutting by color separation |
有Available |
總功率Overall Power |
1800W |
